13.56MHz NXP Mifare Classic EV1 S50 Contactless Chip RFID Smart Card

NXP Mifare Classic EV1 is a high-frequency contactless smart card with an operating frequency of 13.56 MHz, which is widely used in various identification and payment systems. The card provides 1KB or 4KB storage capacity, supports a variety of data storage and encryption functions, and has good security and performance. Mifare Classic EV1 S50 is particularly suitable for applications such as public transportation, access control and e-wallets, and can work stably in a variety of environments. It has strong compatibility and is easy to integrate with various readers and systems, becoming an important part of smart card solutions.

HUYIDA is a professional card, nfc & rfid supplier in China, we can produce plastic card, wooden cards, rfid cards, rfid wristbands, rfid labels, rfid tags, etc.

  • Design: free digital proof sheet, we support .ai, .cdr, .psd, etc.;
  • Requirement: we can help you suggest suitable requirements;
  • Production: we support paid urgent order service;
  • Sample: free printed samples support, if you want to make your own sample card with your design, it needs to be paid;
  • Packing: some jobs like gift cards and carriers/holders/sleeves needs manual operation, we can support;
  • Protective film: some special black cards needs to add protective film and tear off after completion, we can support;
  • Delivery: we support airmail, express, air freight, sea delivery, China Europe freight train;

13.56MHz NXP Mifare Classic EV1 S50 Contactless Chip RFID Smart Card



13.56MHz NXP Mifare Classic EV1 S50 Contactless Chip RFID Smart Card is a widely used contactless smart card that uses 13.56 MHz high-frequency RFID technology. The card has a storage capacity of 1KB or 4KB and supports a variety of data storage and encryption functions. It is suitable for public transportation, access control systems, e-wallets and various identity authentication applications. Mifare Classic EV1 S50 provides higher security and performance, has anti-interference capabilities, and can work stably in a variety of environments. In addition, it also supports a variety of readers and systems, which is convenient for integration and application, and has become an important choice in smart card solutions.



Product Name 13.56MHz NXP Mifare Classic EV1 S50 Contactless Chip RFID Smart Card
Material PVC (Also support PETG, PLA, Wood, ABS)
Size CR80 (85.5 * 54 mm or 3.375×2.125 inch or 3-3/8 “x 2-1/8”) or customized size
Thickness 0.86mm (0.034 inch or 33.86mil), generally customizable to a thickness of no more than 2mm
Corners 1/4 corner radius 3.18mm (r=0.125 inch)
Printing offset printing, screen printing, UV color printing, digital printing, etc.
Lamination Glossy, Matte, Frosted
Personalization laser code, serial number, barcode, QR code, magnetic stripe, etc.
Data Processing Support encryption and decryption
Low Frequency Chips (LF)
ISO 11784/85
TK4100, EM4200/EM4305/EM4450, Atmel T5577/T5567, NXP Hitag 1/Hitag 2/Hitag S256/Hitag S2048, etc.
High Frequency Chips (HF)
ISO/IEC 14443-A | ISO/IEC 15693 | ISO/IEC-18000-3 | ISO/IEC 7816
Fudan FM11RF08S (Fully compatible to NXP S50), NXP Mifare Classic EV1 S50/S70, NXP Mifare Ultralight EV1/C, NXP ICODE SLI/SLIX/ SLIX 2/SLIX-L/SLIX-S/DNA, NXP MIFARE DESFire EV1/Light, NXP NTAG213/215/216
Ultra High Frequency Chips (UHF)
ISO/IEC 18000-6C (63)/ISO/IEC 18000-6D (64) | EPCglobal Class1 Gen2
Alien Higgs 3(H3)/Higgs 9(H9), Impinj Monza 4D/4E/4QT/R6/R6P,  NXP UCODE 7 (U7)/UCODE 8 (U8)/UCODE 8M (U8M)/UCODE 9 (U9)
Contact Chips SLE5542 (SLE4442 updated version) / SLE5528 (SLE4428 updated version) | FM4442/FM4428 | AT24C01/02/04/16/32/64/128/256
Application Scenarios access cards, payment cards, medical cards, identification cards, visiting cards, library cards, bus cards, animal identification cards, anti-counterfeiting cards, transportation cards, campus cards, garbage classification cards, smart trash cans, elevator cards, parking cards, electronic ticketing, electronic gift vouchers, election cards, membership cards, traceability cards, patrol cards, inspection cards, hotel cards, door lock cards, one card system, etc.



LF (Low Frequency) HF (High Frequency) UHF (Ultra High Frequency)
125 KHz | 134.2 KHz
ISO 11784 / 11785
Read only | R/W
Low data speed
1-5cm data reading range
Read only one tag at one time
Used for access control and animal identification
13.56 MHz
ISO 14443A / 14443B / 15693 (NFC ISO 18092)
Read & Write available
Regular data speed
Available for encryption, some support AES-128
2-10cm data reading range (affected by metal)
Multiple tags could be detected at one time
840-960 MHz
ISO/IEC 18000-6C (63)/ISO/IEC 18000-6D (64) | EPCglobal Class1 Gen2
Read & Write available
High data speed
Reach up to 15 meters data reading range
Multiple tags could be detected at one time
Signal could be easily influenced by metal, water, wall, human body, etc.
